Most enterprise systems already use patterns from Martin Fowler’s Patterns of Enterprise Application Architecture. The twist is that many teams use them without naming them, half implement them and then wonder why the codebase fights back.

If your ASP.NET solution contains controllers that talk straight to SQL, services that return HTTP responses, and entities that call SaveChanges, you are already remixing Fowler’s patterns. You are just doing it implicitly and at great expense.

This series takes the opposite route. We will name the patterns, show where they fit, and implement each one in C# with concrete examples.

You will see where these patterns help, where they hurt, and how they combine into real architectures instead of diagram fantasies.

How this series will work

In each article, I will:

Explain a pattern in plain language, with the original intent from Fowler’s catalog
Show how it typically shows up in C# and .NET projects
Give a focused example of when to use it and when to avoid it
Connect it to neighboring patterns so you see design options, not isolated tricks

This introduction maps the territory. Every item in the index below links to a short description, a definition, and an example scenario. Each of those sections will become a full post with code.

Pattern index

Use these links to jump to the pattern you care about right now.

Layered Architecture
Transaction Script
Domain Model
Service Layer
Active Record
Data Mapper
Repository
Unit of Work
Identity Map
Lazy Load
Front Controller
Model View Controller (MVC)
Data Transfer Object (DTO)

Each section below is both a preview and a contract for the dedicated C# article that will follow.

Layered Architecture Pattern

Definition

Layered Architecture splits an application into distinct layers with clear responsibilities. Fowler’s baseline is:

Presentation: handles input and output
Domain: holds business rules and domain logic
Data source: manages persistence and integration with data stores

The core rule is brutal and simple: if your controllers know SQL or your repositories know HTTP, the layers have already collapsed.

Where to use it

Layered Architecture fits:

ASP.NET Core applications that will grow beyond a few controllers
Systems where different teams own UI, business rules, and infrastructure
Codebases that must survive several technology shifts over their lifetime

In the dedicated post you will see a C# solution where projects align with layers, controllers stay thin, domain services stay ignorant of transport, and repositories encapsulate EF Core without leaking it upward.

Transaction Script Pattern

Definition

Transaction Script organizes business logic as procedures that handle a single request or use case end to end. Each script:

Reads input
Performs calculations and decisions
Persists changes

There is minimal domain modeling. The focus stays on the flow of a transaction.

Where to use it

Transaction Script works best when:

The domain logic is simple and shallow
You are building reports, admin utilities, or migration tools
You need results quickly and long term complexity is limited

In C#, this often appears as an application service or handler class that works directly with DbContext and simple DTOs. In the article you will see both the benefits and the trap: it feels efficient until rules start to repeat across scripts.

Domain Model Pattern

Definition

Domain Model concentrates business rules inside a rich object model. Entities and value objects express invariants and behavior.

Instead of treating data as passive structures, you treat the domain as the center of gravity. Controllers and repositories orbit around it rather than injecting rules into every edge of the system.

Where to use it

Domain Model earns its weight when:

The business rules are complex and interdependent
Invariants matter more than raw throughput
You expect requirements to evolve frequently

In C# this means entities with methods that enforce rules, factories that control creation, and services that orchestrate multiple aggregates. The dedicated post will show an aggregate in code, along with tests that lock in behavior before you worry about EF mapping.

Service Layer Pattern

Definition

Service Layer defines a set of application operations that sit between the outside world and the domain model. It:

Coordinates multiple domain objects
Handles transactions and security policies
Exposes a clear API for controllers, message handlers, or other clients

It is the point where use cases live.

Where to use it

Service Layer fits when:

You have multiple clients hitting the same core logic: web, background jobs, workers
You want to expose a stable application API while the UI evolves
Cross cutting concerns such as logging, permissions, and transaction boundaries must stay consistent

In .NET this often becomes a set of application service classes injected into controllers and workers. In the article you will see a C# service layer that makes HTTP a detail, not the boss.

Active Record Pattern

Definition

Active Record merges domain objects with persistence. Each entity:

Maps directly to a database row
Contains business logic
Knows how to load and save itself

Fowler treats it as a close fit for simple domains where the object model mirrors the database closely.

Where to use it

Active Record suits:

Small systems with straightforward tables
Prototypes where getting something working matters more than deep abstraction
Places where simple CRUD with light behavior is enough

In C#, you often see Active Record flavor when EF Core entities call SaveChanges directly or static methods perform global queries. The dedicated post will show a disciplined version of Active Record and explain when to retire it in favor of a separate Data Mapper.

Data Mapper Pattern

Definition

Data Mapper sits between domain objects and the database. It:

Loads domain objects from data stores
Persists changes back
Shields the domain from knowledge of how persistence works

The domain classes stay persistence ignorant. The mapper takes on the burden of translation.

Where to use it

Data Mapper pays off when:

You have a rich Domain Model
The database schema must evolve independently of the object model
You want to test domain logic without a database in the way

In .NET, EF Core already plays the Data Mapper role. The article will show how to design domain classes that do not depend on EF, then map them using configurations and repositories that wrap the mapper.

Repository Pattern

Definition

Repository represents a collection-like interface for accessing aggregates. It:

Hides queries and persistence details
Exposes methods that work in domain terms, such as GetById, FindActiveForCustomer, Add, Remove
Lets the domain talk in its own language instead of in SQL or query APIs

Fowler includes Repository in the object relational patterns as a way to further isolate domain logic from data access.

Where to use it

Repository helps when:

The same aggregate appears across many use cases
You want consistent access patterns for aggregates
You expect to support multiple query strategies or stores behind the same domain interface

In C#, this usually means interface definitions in the domain layer and implementations in an infrastructure project. The dedicated post will include concrete repository designs, and also examples of where a repository introduces more indirection than it earns.

Unit of Work Pattern

Definition

Unit of Work tracks changes to domain objects during a business transaction and writes them out as a single logical batch. It:

Records inserts, updates, and deletes
Coordinates commit or rollback
Provides a boundary for transactional behavior

Fowler presents it as a way to stop writes from spreading unpredictably through a codebase.

Where to use it

Unit of Work is valuable when:

A single operation touches multiple aggregates or tables
You need clear transactional boundaries for consistency
You want to keep domain logic free of save calls

In .NET, DbContext already behaves as a Unit of Work, yet many codebases hide that fact. The article will show how to embrace this pattern explicitly and how to wrap EF Core in a higher level unit of work abstraction when needed.

Identity Map Pattern

Definition

Identity Map ensures that each logical entity from the database exists only once in memory per scope. It:

Tracks loaded objects by identity
Returns existing instances instead of creating new ones for the same key
Helps avoid inconsistent in memory states for the same row

This pattern often works with Unit of Work and Data Mapper.

Where to use it

Identity Map matters when:

The same entity is loaded through different paths in one request
You attach domain behavior to entities and depend on reference equality
You care about performance costs of repeated materialization

ORMs such as EF Core implement identity maps under the surface. The dedicated post will explain what EF is doing for you and show how to apply Identity Map explicitly when you move outside of ORMs or use multiple contexts.

Lazy Load Pattern

Definition

Lazy Load defers loading of related data until it is actually needed. Instead of fetching entire object graphs, you:

Load a root entity
Represent associations as placeholders
Trigger actual loading when code accesses the association

The pattern targets performance and memory by avoiding unnecessary work.

Where to use it

Lazy Load helps when:

Most use cases do not need full graphs
Some navigations are expensive or remote
You have to control query explosions carefully

In .NET, EF Core can use lazy loading proxies, or you can code your own lazy associations. The article will show both approaches and highlight the risk: invisible queries that surprise you in performance profiles.

Front Controller Pattern

Definition

Front Controller centralizes request handling for a web application. Instead of letting every page or endpoint own its own entry point, you:

Route all requests through a single handler
Apply cross cutting logic in one place
Delegate to controllers or handlers for detailed work

Fowler introduces it as a response to duplicated request handling logic.

Where to use it

Front Controller aligns with:

Web applications that need consistent logging, authentication, and error handling
Systems that must make routing decisions based on shared policies
Architectures that use pipelines and middleware

In ASP.NET Core, the combination of the hosting pipeline and routing already forms a Front Controller. The dedicated post will show how to control that pipeline intentionally instead of treating it as framework magic.

Model View Controller (MVC) Pattern

Definition

Model View Controller splits UI logic into three parts:

Model: the underlying data and behavior
View: rendering logic
Controller: input handling and coordination

Fowler’s version focuses on server side web MVC.

Where to use it

MVC suits:

Applications with complex UI interactions that depend on domain rules
Teams that want clear separation between presentation logic and domain logic
Systems that must support multiple views on the same model

In ASP.NET Core MVC, controllers speak to application services, views render models, and domain rules stay out of both. The article will show how to keep controller code lean instead of letting it morph into a second application layer.

Data Transfer Object (DTO) Pattern

Definition

Data Transfer Object carries data across process boundaries. It:

Aggregates fields into a serializable shape
Avoids sending full domain objects across the wire
Provides a contract between services, clients, or layers

DTOs trade object richness for stability and clarity at integration points.

Where to use it

DTOs are worth the effort when:

You are exposing public APIs
Multiple clients consume your service, each with their own evolution pace
You want to keep domain classes internal to your application

In C#, DTOs typically appear as record types in API projects or as message contracts in messaging systems. The article will show mapping patterns between domain objects and DTOs and how to keep them from overflowing with accidental complexity.

What comes next

The rest of this series will go pattern by pattern:

Each pattern gets its own post
Each post includes C# examples, tests where relevant, and context from real projects
The focus stays on tradeoffs, not worship of diagrams

You can read the series start to finish, or you can drop directly into the pattern that matches the pain in your current system and work outward from there.

If your code already resembles these patterns, this series gives you language and structure. If it does not, the upcoming posts will show how to reshape it piece by piece without pausing delivery.
